Check valve - Stainless Steel body - DN20 - PN40 - WAFER - GN10/16/25/40 & ANSI 150 - max. 240°C
Reference :
CHWX.007.020
Brand reference :
2415 05
| Specifications | |
| Body material | |
| Sealing | |
| Connection diameter | |
| Nominal geometry | |
| Nominal pressure | |
| Fluid operating temperature |
Stainless steel disc check valve
- DN 20
- Flange connection according to EN 1092 PN10/16/25/40 and ANSI 150/300
- PN 40
- Flow coefficient Kv 8,8 m³/h
- Body and disc in stainless steel CF8M
- Spring in stainless steel AISI 316
- Metal/Metal seal
- Fluid temperature range -20°C to +240°C
- Opening pressure between 24 and 30 mbar
- Spacing according to EN 558-1 series 49
- Installation with vertical, horizontal or inclined flow
- With centering ring
- DN 20
- Flange connection according to EN 1092 PN10/16/25/40 and ANSI 150/300
- PN 40
- Flow coefficient Kv 8,8 m³/h
- Body and disc in stainless steel CF8M
- Spring in stainless steel AISI 316
- Metal/Metal seal
- Fluid temperature range -20°C to +240°C
- Opening pressure between 24 and 30 mbar
- Spacing according to EN 558-1 series 49
- Installation with vertical, horizontal or inclined flow
- With centering ring
| Specifications | |
| Body material | |
| Sealing | |
| Connection ends | |
| Connection diameter | |
| Nominal geometry | |
| Nominal pressure | |
| Fluid operating temperature | |
| Operation | |
| Compatibility – Fluids |
|
| Intrastat code |
|
| Gross weight |
|
| Country |
|
| ECLASS code |
|
| UNSPSC code |
|
