Filter - Bronze body - PTFE - G1/2'' FF - PN16 - Hor./ver. assembly - 400 µm - (+)110°C
Reference :
STTX.002.012
Brand reference :
3304 04
Y-Filter :
- Threaded connection G 1/2" according to ISO 228/1
- Maximum operating pressure 16 bar
- Flow coefficient Kv 3,30 m³/h
- Bronze body
- Brass cover
- AISI 304 stainless steel strainer
- Fibre cover gasket
- Filtration : 0,4mm
- Operating temperature range -10°C to +110°C
- Threaded connection G 1/2" according to ISO 228/1
- Maximum operating pressure 16 bar
- Flow coefficient Kv 3,30 m³/h
- Bronze body
- Brass cover
- AISI 304 stainless steel strainer
- Fibre cover gasket
- Filtration : 0,4mm
- Operating temperature range -10°C to +110°C
| Body material | |
| Sealing | |
| Filtration | |
| Connection ends | |
| Connection diameter | |
| Nominal pressure | |
| Fluid operating temperature | |
| Operation | |
| Compatibility – Fluids |
|
| Intrastat code |
|
| Gross weight |
|
| Country |
|
| ECLASS code |
|
| UNSPSC code |
|
| Related product no. 11 |
|
